Intel® Server S2600CW Product Family Configuration Guide and Spares/Accessories List
12
Intel Product Code (iPC):
iPC – P4304XXMUXX
Order Code Information:
MM# - 937011
UPC - 00735858289962
EAN - 5032037068802
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: 4U rack mount
Chassis dimensions: L=612mm, W=173mm,
H=438mm
Packaged Gross Weight: 23.8 Kgs, 52.4 Lbs
Un-packaged Net Weight: 15.5 Kgs, 34.2 Lbs
Outer Box Dimensions: L=813mm, W=348mm,
H=577mm
Product Definition and Configuration Requirements
Intel product code P4304XXMUXX includes the
following components:
(1) – 4U Chassis
(1) - Standard Control Panel – iPC FXXFPANEL
(1) - Power Distribution Board – iPC FUPPDBHC2
(1) – Power Supply Cage – iPC FUPCRPSCAGE
(5) – Redundant/Hot swap 80mm system fans - iPC
FUPMLHSFAN
(4) - Fixed 3.5”/2.5” drive sleds - iPC FUP4X35NHDK
(1) – Processor/Memmory air duct – iPC A4UCWDUCT
(1) – Hot swap bezel with lock – iPC FUPBEZELHSD2
(1) – Fixed EMI cover
(1) - Attention documention
(2) – Dual power Connector Cable iPN – G22872-00x
(1) – MiniSAS HD to 4 ports SATA 7 pins cable –
AXXCBL450HD7S
(1) – Chassis plastic Foot iPN – G35111-00x
(1) – Set of standoffs for Motherboard iPN – G35101-
00x
(1) – Bumper pad for Motherboard iPN – G35112-00x
(1) – Set of 5mm screws for Motherboad iPN – G35096
Required Items – Sold Separately:
• Intel® Server Board S2600CW (choose one)
o iPC DBS2600CW2R – with dual 1GbE NIC
ports
o iPC DBS2600CWTR – with dual 10GbE NIC
ports
o iPC DBS2600CW2SR – with dual 1GbE NIC
ports and onboard SAS controller
o iPC DBS2600CWTSR – with dual 10GbE NIC
ports and onboard SAS controller
• Power Cord(s)
NOTE: Chassis shipped to the US & Canada
will contain North American power cords.
• 1 or 2 Intel® Xeon® E5-2600 v3 or v4 product family
processors
• ECC DDR4 memory (RDIMM)
•
SATA cables
Optional Intel Accessories – Sold Separately:
• Intel® I/O Module – See Chapter 5 for options.
• Intel® SAS RAID Card / Module – See Section 4.3 for
options.
• Power supply - See 0 Section for options.
• SAS/SATA backplane - See Section 4.1 for options.
• Hot swap drive cages - See Section 4.1 for options.
• iPC AXXRMM4LITE – Intel® Remote Management
Module Lite key. For advanced management
features
• Storage Drives
See Chapter 4 for all available accessory options.
