Intel® Server Board SE7520JR2 Platform Management
Revision 1.0
C78844-002
143
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Critical Inerrupt
Sensor
07h
Critical Interrupt
13h
Sensor
Specific
6Fh
Front Panel NMI
Bus Error
As & De – Trig Offset A –
Memory 08h
Memory
0Ch
Sensor
Specific
6Fh
Uncorrectable
ECC
As – Trig Offset A –
Event Logging
Disabled
09h
Event Logging
Disabled
10h
Sensor
Specific
6Fh
Correctable
Memory Error
Logging Disabled
Log Area
Reset/Cleared
As – Trig Offset A X
Session Audit 0Ah
Session Audit
2Ah
Sensor
Specific
6Fh
Session Activation
Session
Deactivation
As –
As defined
by IPMI
A X
BB +1.2V Vtt 10h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB+1.2V
NIC Core
11h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A X
BB +1.5V 12h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +1.8V
SCSI Core
13h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +2.5V Memory
Voltage
14h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +3.3V 15h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
BB +3.3V Standby 16h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +3.3V AUX 17h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +5V 18h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB +5V Standby 19h
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
BB +12V 1Ah
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB -12V 1Bh
Voltage
02h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
BB Vbat 1Ch
Voltage
02h
Digital
Discrete
05h
Limit Not
Exceeded
Limit Exceeded
As & De – R, T A X
BB Temp 30h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
Front Panel Temp 32h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A X
Drive Backplane
Temp
35h
Temp
01h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T A –
