Platform Management Intel® Server Board SE7520JR2
Revision 1.0
C78844-002
144
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Tach Fan 1 40h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 2 41h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 3 42h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 4 43h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 5 44h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 6 45h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 7 46h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 8 47h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 9 48h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 10 49h
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Tach Fan 11 4Ah
Fan
04h
Threshold
01h
[u,l][nr,c,nc] As & De Analog R, T M –
Digital Fan 1 50h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 2 51h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 3 52h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 4 53h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 5 54h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 6 55h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 7 56h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 8 57h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
Digital Fan 9 58h
Fan
04h
Digital
Discrete
06h
Performance Met
or Lags
As & De – Trig Offset M –
