Intel® Server Board SE7520JR2 Error Reporting and Handling
Revision 1.0
C78844-002
159
Message Displayed Description
configure IDE/ATAPI devices in POST.
Secondary Master Drive - ATAPI Incompatible The IDE/ATAPI device configured as Secondary Master
failed an ATAPI compatibility test. This message is
typically displayed when the BIOS is trying to detect and
configure IDE/ATAPI devices in POST.
Secondary Slave Drive - ATAPI Incompatible The IDE/ATAPI device configured as Secondary Slave
failed an ATAPI compatibility test. This message is
typically displayed when the BIOS is trying to detect and
configure IDE/ATAPI devices in POST.
3
rd
Master Drive - ATAPI Incompatible The IDE/ATAPI device configured as Master in the 3
rd
IDE controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
3
rd
Slave Drive - ATAPI Incompatible The IDE/ATAPI device configured as Slave in the 3
rd
IDE
controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
4
th
Master Drive - ATAPI Incompatible The IDE/ATAPI device configured as Master in the 4
th
IDE controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
4
th
Slave Drive - ATAPI Incompatible The IDE/ATAPI device configured as Slave in the 4
th
IDE
controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
5
th
Master Drive - ATAPI Incompatible The IDE/ATAPI device configured as Master in the 5
th
IDE controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
5
th
Slave Drive - ATAPI Incompatible The IDE/ATAPI device configured as Slave in the 5
th
IDE
controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
6
th
Master Drive - ATAPI Incompatible The IDE/ATAPI device configured as Master in the 6
th
IDE controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
6
th
Slave Drive - ATAPI Incompatible The IDE/ATAPI device configured as Slave in the 6
th
IDE
controller failed an ATAPI compatibility test. This
message is typically displayed when the BIOS is trying to
detect and configure IDE/ATAPI devices in POST.
S.M.A.R.T. Capable but Command Failed The BIOS tried to send a S.M.A.R.T. message to a hard
disk, but the command transaction failed.
This message can be reported by an ATAPI device using
the S.M.A.R.T. error reporting standard. S.M.A.R.T.
failure messages may indicate the need to replace the
hard disk.
S.M.A.R.T. Command Failed The BIOS tried to send a S.M.A.R.T. message to a hard
disk, but the command transaction failed.
This message can be reported by an ATAPI device using
the S.M.A.R.T. error reporting standard. S.M.A.R.T.
failure messages may indicate the need to replace the
hard disk.
S.M.A.R.T. Status BAD, Backup and Replace A S.M.A.R.T. capable hard disk sends this message
when it detects an imminent failure.
This message can be reported by an ATAPI device using
the S.M.A.R.T. error reporting standard. S.M.A.R.T.
failure messages may indicate the need to replace the
hard disk.
S.M.A.R.T. Capable and Status BAD A S.M.A.R.T. capable hard disk sends this message
