Marking of the Antenna’s Parking Position
Referring to the Mounting template, mark where antenna is to be
mounted onboard the ship (it must be a at surface) or on a separate
power tower by drawing a square of 14.4cm (5.7”)
Figure 09 : Intellian i2
Note:
If a power tower is not used to mount the antenna, separate
cable shocks and waterproong measures must be taken to protect the
RF connector from being exposed to sea water and external shocks. An
exposed cable may cause electric shock and cause serious damage to
the equipment.
