Intellian i2 - Operating the ACU; ACU Soft Keys Overview; Normal Mode Startup Sequence

27
Operation Using the ACU
ACU Soft Keys
Normal Mode
Start Up
With the system installed and power applied, the ACU screen will show
the following sequence:
1. Data communication is being established
between the antenna and the ACU. The ACU
is initialized.
2. The antenna is initialized.
3. The antenna is searching for Satellite A.
4. The antenna has located the satellite and is
now tracking.
INITIALIZE ACU
INITIALIZE ANTENNA
SEARCH A: DTV101
TRACKING A: DTV101
INTELLIAN i2
INTELLIAN i2
B:DTV119 SETUP
B:DTV119 SETUP
Figure 25 : ACU Soft Keys
Press to select
On-screen option
BACK
ENTER
POWER
