Intellian i2 User Manual

74
Intellian Satellite TV Antenna Systems
General
Approvals
CE – conforms to
FCC – veried to
EU Directive 89/336/EEC
CFR47:Part 15
Dimensions
Satellite antenna unit
Antenna dish diameter
Antenna control unit
37cm (14.6”) x 38cm(15”)
33cm(13.3”)
17.8cm(7”)x21.7cm(8.5”)x5.4cm(2.1”)
Weight
Satellite antenna unit
Antenna control unit
4.5kg (9.5 lbs)
1.2kg (2.6 lbs)
Environmental
Operating temperature range
Storage temperature range
Humidity limit
-25°C to +55°C (-13°F to +131°F)
-40°C to + 80°C (-40°F to + 176°F)
95% R.H
Operating voltage 9 ~ 30V D C
Power consumption Typ. 30W, Max. 50W
Antenna system performance
Frequency Ku-band (10.7 to 12.75 GHz)
Minimum EIRP 51 dBW
Azimuth range 680°
Elevation range +10° ~ +80°
Ship’s motion
Roll ±25°
Pitch ±15°
Roll and pitch
response rate
60° per second
Turn rate 60° per second
Appendix : i2 Technical Specication

Intellian i2 Specifications

General

Brand	Intellian
Model	i2
Category	Antenna
Language	English
