Intellian Satellite TV Antenna Systems
Auto LNB Skew Angle Adjustment for i4P
Intellian i4P has an embedded auto skew angle control system.
Therefore, manual adjustment of LNB skew angle is not required. The
LNB skew angle is continuously adjusted automatically through of the
calculation of current GPS location and target satellite. The skew angle
of LNB is shown from the ACU and GUI Program.
Figure 25 : Auto LNB Skew Angle Adjustment System
PC to ACU Communication Setup
You can establish data communication between a PC and the ACU using
one of the following methods.
Serial Connection
Connection through Serial Port
1. Connect a 9-pin Serial cable from the PC INTERFACE connector on the
ACU to the 9-pin serial port on your PC.
2. If there is not a 9-pin serial port on the PC, use a USB-Serial adapter.
Figure 26 : Serial Connection
