Intelligent Mediator – Marine Satellite Communication System
Aptus
Web for the Mediator
Introduction
With embedded Aptus Web software, the Mediator can
be monitored and controlled remotely through the TCP/IP
protocol.
How to access Aptus Web for the Mediator
1. Connect an Ethernet cable from the M&C port on the
front of the Intelligent Mediator to the LAN port of PC.
This method is most recommended.
2. Enter the Mediator’s IP address (192.168.2.1) into your
web browser’s address bar to login into the Mediator’s
internal HTML page, if this system has not been changed
from the Mediator’s factory default. You’ll be able to
access this page within about 1 min after the Mediator
power is on.
NOTE: Aptus Web can be displayed on the Internet
Explorer 8 or later and is also compatible with
Firefox and Chrome web browsers.
