Intelligent Mediator – Marine Satellite Communication System
Planning Installation
Installation Kit
Before beginning installation, make sure you have all the included components.
Description Q'ty Size Remarks
Intelligent
Mediator
1
43.1
x 38 x
8.8cm
2U Type Mediator Unit
User Guide 1 For Mediator Unit
Mediator Side
Bracket (Rack)
2 Mediator to 19inch Rack
Mediator Side
Bracket (Table)
2 Mediator to Table
Flat Head Screw 16 M4x12L
Bolt Kit for Rack Mount
Bracket
Self-Tapping
Screw
5 M4x16L
Bolt Kit for Table Mount
Bracket
Sems Bolt 5 M3x12L
SMA(M) to
SMA(M) Cable
3 1.3m Mediator to Modem(ACU)
N(M) to N(M)
Cable
3 1.3m Mediator to Modem(ACU)
N(M) to SMA(F)
Adaptor
3
Description Q'ty Size Remarks
Modem
Interface Cable
(For Comtech
Modem_DB-9
pin Female)
2 1.5m
Mediator(RS232&Console:C-
band, Ku-band) to Modem
(Comtech Modem:C-band,
Ku-band)
RG6 Cable
(RF Cable)
4 3m
For RX/TX connection:
Mediator to Modem(C-band,
Ku-band)
PC Serial Cable 2 1.8m
For seriel modem & BUC
interface
Ethernet Cable
(RJ45 / LAN)
3 1.5m ACU to PC/Intellian M&C
AC Power Cord
(CEEE7/7)
1 1.5m Mediator Power (220V)
AC Power Cord
(USA)
1 1.5m Mediator Power (110V)
USB Cable (A-A) 1 1.8m Mediator to PC
D-Sub 9
pin Female
Connector
2
For Mediator-Modem
Interface
To Next Page
