Intelligent Mediator – Marine Satellite Communication System
Technical Specification
Dimension
(W x D x H)
431mm X 381mm X 89mm
(17” X 15” X 3.5”)
Weight 4.5Kg (9.9 lbs)
LED Indicator
3LEDs for Power, Mediator and M&C
Server
3LEDs for Antenna 1, Antenna 2 and
Antenna 3
12LEDs for Antenna bands
Ethernet Port
Front Panel
RJ45, TCP/IP connection,
Support Web & M&C port
Rear Panel
Support Web & M&C port,
RJ45(8-Ports)
USB Port
Upper Port
i-ARM Connection, Main
Connection, Logs Download
& Update
Lower Port
PC or Management
Device(57600bps)
Ship’s
Gyrocompass
Interface
NMEA2000 / NMEA0183
Modem
Interface
RS-232C / I/O ports / Ethernet
BUC Interface RS232 / I/O PORTS
PC Serial
Interface
RS232 (19200bps, 8, N, 1)
Channel
• TX: 4X3 Matrix Switch
• RX: 3X5 Matrix Switch
Gain
• TX: 0dB typ.
• RX: 10dB typ.
Gain Control
Range
(RX Only)
30dB (0.5dB Step)
Port Isolation
• TX: 45dB typ.
• RX: 50dB typ.
Impedance
• 50ohm: SMA, N-Type
• 75ohm: F-Type
Connectors
• 50ohm: SMA-Type(Female),
N-Type(Female)
• 75ohm: F-Type(Female)
Frequency
Range
950MHz ~ 2150MHz (Reference Signal:
10MHz, 50MHz)
Power Source 100 ~ 240 V AC, 50 ~ 60Hz, 1A
Power
Consumption
20W Typ.
