Intelligent Mediator – Marine Satellite Communication System
No. Item Description
2
Dashboard
Items
- Abs AZ(Absolute Azimuth): displays
antenna absolute AZ angle.
- Heading: Displays ship’s heading
information.
- EL: Displays antenna relative elevation
angle.
- TX: Displays transmit status(On or Off).
- Lat: Displays GPS latitude.
- Long: Displays GPS Longitude.
- Pol: Displays Rx/Tx Polarization.
- Demod: Displays lock status of the
modem as Lock, Unlock in GEO
satellite. When using MEO Ka-band
satellite, the “Unlock/Off, Unlock/
On, Lock/Off, Lock/On” options are
displayed. The following ve options
are displayed as “option name-X”(X is
A or B).
• Fault: The modem demodulation is
unsuccessful.
• Unlock/Off: The modem is unlocked
and Off state.(The Off means the
modem is not carrying trafc.)
• Lock/Off: The modem is locked and
Off state.
• Unlock/On: The modem is unlocked
and On state.(The On means the
modem is carrying trafc.)
No. Item Description
2
Dashboard
Items
• Lock/On: The modem is locked and
On state.
NOTE: This function is also displayed in
the Top Menu for a quick monitoring.
- Status: Dispays antenna’s status.
(Normal or Fault)
- Es/N0: Displays energy per symbol to
noise power spectral density.
3
Information
- Control IP: Displays current IP that
controls the Mediator.
- Current IP: Displays current IP
address.
- Refresh Rate: Displays screen refresh
rate (default: 1 sec.)
- Refresh Disable: Displays time out.
The screen will not refresh once the
time-out shows 0:00. ( Exception: If the
Refresh Disable Time is set to “OFF”
in the Network Setting page, then the
clock will show “--:--” and the system
will keep monitoring all activities
regardless of the timeout.)
- Time: Displays UTC time.
- Date: Displays UTC date.
- H/O Countdown: Displays the time
remaining until the next satellite is
reached.
