75
reference. The system is not able to be automatically calculated the
exact center value, therefore, it is necessary to perform this procedure to
manually enter any offset required to make sure the PCU receives a true
reference to the horizon.
Diagnosis: If “Diagnosis” button is pressed, the system will carry out
the selected full diagnosis “Test All” or single diagnosis. The software will
display the diagnosis results (Blue dot represents “normal”, red
represents “abnormal” and green represents “the diagnosis is under
process”).
Set EL Adjust: To offset the angle difference between the mechanical
elevation angle and actual elevation angle.
Calibration Gyro: Calibrate the bias of gyro sensor located on the
sensor box. Before calibrating the gyro sensor, make sure that the
antenna is placed on a rigid and flat platform. During the calibration
process, the antenna should avoid any motion as it can affect the
antenna’s performance. After clicking the “Calibration Gyro” button, the
green dot will be displayed as a ready signal to calibrate the gyro sensor.
The red dot (fail) or blue dot (pass) will be displayed once the calibration
is completed,
Idle Mode: To release the EL/CL BLCD motor brakes during the
“Setup mode”. The antenna can be moved manually during the idle
mode. It is required to turn off and turn on the ACU power to bring the
antenna out of the idle mode.
PC Controller Program
