3 Introduction
Satellite Modem
(Not supplied)
Antenna Control Unit
AC
110/220V
NMEA/Synchro/SMS
TCP/IP
8W BUC
Power (+48V)
Tx
Rx
Rx/Power/Data
Ship’s
Gyrocompass
(Not supplied)
Basic System Configuration
For your satellite communication system to work properly, the system
will have to be connected with all of the provided components properly,
as shown in the figure below (see the “Installation” section of this
manual). Separate purchase of a satellite modem is required.
Figure 1. Basic System Configuration
