Intelligent Weighing Technology QHD+3 User Manual

- 35 -
14. SPECIFICATIONS
DIMENSION
Specification
MODEL QHD+ 3 QHD+ 6 QHD+ 15 QHD+ 30
Maximum Capacity 3000 g 6000 g 15 kg 30 kg
Readability 0.05 g 0.1 g 0.2 g 0.5 g
Tare Range -3 kg -6 kg -10 kg -30 kg
Repeatability(Std Dev) 0.05 g 0.1 g 0.2 g 0.5 g
Linearity ± 0.1 g 0.2 g 0.5 g 1 g
Units of Measure lb, kg
Interface Bi-directional RS-232 Interface
Stabilization Time 2 Seconds
Operating Temperature 0°C - 40°C (32°F - 104°F)
Power supply AC Adaptor 9 V/800 mA / Battery 6V4AH
Calibration Automatic external
Display 3 x 6 digits LCD digital display with white LED back
light
Housing Indicator ABS Plastic, Stainless Steel pan
Pan size 225 x 300mm / 8.9 x 11.8”
Overall dimensions 320 x 340 x 125mm / 12.6 x 13.4 x 4.9”
Net weight 4.3kg / 9.5lb
Applications Counting Scale
Internal Resolution Up to60000
