Specification for Remote Scale
Excitation voltage 5 VDC
Signal range 0-20 mV(allows 3 mV/V LC with 5mv zero offset)
Zero range 0-5 mV
Sensitivity 0.02 µV/internal ADC count or better
Internal ADC counts 500,000 maximum at 10 mV input
Load 87 ohm minimum, 4 X 350 ohm load cells
Connection 4 wire connection to load cells plus shield
Maximum cable length 6 meters
Termination 9 pin d-subminiature plug on scale
Specification for Local Scale Load Cell
Model No C2X1
Rated Capacity 6~50 (kg)
Rated Out put 2.0 mV/V±0.2 mV/V
Excitation Voltage 20 VDC
IP Level IP64
Material Aluminum Alloy
Cable Φ8.2 four core shield
Input Resistance 420Ω±30Ω
Out put Resistance 350 Ω ± 5 Ω
Temperature
Range
-10°C - 50°C
Safe overload 150 %R.C
Ultimate overload 200 %R.C
Repeatability 0.02 %R.O
Creep 0.02 %R.O/ 20min
Zero Balance ± 0.1 mV/V
