IntelliTech International, Inc. Programmer’s Guide | 1
33 Thermal Printer Programmer’s Guide
TRANSCURRENTRIGHT
4
Transmissive sensor current for
the outside sensor
0-32 16
REFLCURRENTUPLEFT
4
Reflective sensor gain for the
top inside sensor
0-32 16
REFLCURRENTUPRIGHT
4
Reflective sensor gain for the
top outside sensor
0-32 16
REFLCURRENTDOWNLEFT
4
Reflective sensor gain for the
bottom inside sensor
0-32 16
REFLCURRENTDOWNRIGHT
4
Reflective sensor gain for the
bottom outside sensor
0-32 16
FRONTPANELUNITS The units displayed on the
printer front panel
IMPERIAL, METRIC IMPERIAL
TIMEONFRONTPANEL Used to display time on the front
panel, or not
OFF, ON OFF
MAINTENANCEALARMDIST This notifies the user when
maintenance is required. It is
specified in thousands of
inches. 0 is no alarm.
0 – 1000 (1000”) 0
ERRORRECOVERY Used to reprint labels after an
error, or not
REPRINT, NORERPINT REPRINT
PASSWORD Default password for PJL
security
0 – 65535 0
TIMEOUT Used to set the duration of I/O
timeout in seconds. If the printer
waits longer than the timeout
value without receiving any
data, it ends the print job and
begins accepting data from
other I/O ports.
0-300 (s) 1
COPIES
7
The number of copies of each
label for a print job
1 – 9999 1
PORTNUMBER The TCP port number 0 - 65535 9100
DISKLOCK Prevents writing to user flash OFF, ON OFF
GPIO Enables use of external GPIO
device
OFF, MODE1 OFF
GPIOSIGNALTYPE1 Selects the type of input/output
signal for pin 1
LOW, HIGH, LOWPULSE,
HIGHPULSE, EDGE
LOW
GPIOSIGNALTYPE2 Selects the type of input/output
signal for pin 2
LOW, HIGH, LOWPULSE,
HIGHPULSE, EDGE
LOW
GPIOSIGNALTYPE3 Selects the type of input/output
signal for pin 3
LOW, HIGH, LOWPULSE,
HIGHPULSE, EDGE
LOW
GPIOSIGNALTYPE4 Selects the type of input/output
signal for pin 4
LOW, HIGH, LOWPULSE,
HIGHPULSE, EDGE
LOW
GPIOSIGNALTYPE5 Selects the type of input/output
signal for pin 5
LOW, HIGH, LOWPULSE,
HIGHPULSE, EDGE
LOW
Variable Description Range Default
