MIXING CONSOLE
11
IMX-824/832/840
2. REAR PANEL
1. SIGNAL INPUTS
The XLR-type and TRS stereo inputs are intended for line-level
signals. The TRS jacks may be used with signals that are 6dB
higher in level than the signal inputs to the XLR connectors. The
XLR and TRS connectors for each channel are summed
together prior to the input preamplifier. The nominal input
impedance of the both XLR and TRS inputs are 10k.
