IMX-824/832/840
Specifications
Specifications......................................................
*0dBu=0.775V, 0dBV=1V
IMX-824 IMX-832 IMX-840
MIC INPUT XLR 3 type female Electronically Balanced
Input Impedance >2kΩ
Nominal Level -60dBu to +10dBu(+30dBu Max.)
Hi-Z INPUT TRS Jack socket Electronically Balanced
Input Impedance >30kΩ
Nominal level -34dBu to +36dBu
STEREO INPUT(1) XLR3 type female Electronically Balanced
Input Impedance >10kΩ
Nominal level -20dBu to +10dBu(+30dBu Max.)
STEREO INPUT(2) TRS Jack socket Electronically Balanced
Input Impedance >10kΩ
Nominal level -14dBu to +16dBu
RETURN INPUT TRS Jack socket Electronically Balanced
Input Impedance >10kΩ
Nominal level -10dBv/+4dBu(+10dBv/+24dBu Max.)
PB INPUT RCA pin type Unbalanced
Input Impedance >15kΩ
Nominal level -10dBv
INSERTION RETURN TRS Jack socket Electronically Unbalanced
Input Impedance >15kΩ
Nominal level 0dBu(+20dBu Max.)
TB MIC INPUT XLR3 type female Electronically Balanced
Input Impedance >3kΩ
Nominal level -60dBu to -22dBu
MIX OUTPUT XLR3 type male Electronically Balanced
Output Impedance <150Ω
Minimum load >600Ω
Nominal level 0dBu(+22dBu Max.)
GROUP OUTPUT XLR3 type male Electronically Balanced
Output Impedance <150Ω
Minimum load >600Ω
Nominal level 0dBu(+22dBu Max.)
AUX OUTPUT XLR3 type male Electronically Balanced
Output Impedance <150Ω
Minimum load >600Ω
Nominal level 0dBu(+22dBu Max.)
