MIXING CONSOLE
30
IMX-824/832/840
MONITOR OUTPUT XLR3 type male Unbalanced
Output Impedance <150Ω
Minimum load >2kΩ
Nominal level 0dBu(+18dBu Max.)
INSERTION SEND TRS Jack socket Unbalanced
Output Impedance <150Ω
Minimum load >2kΩ
Nominal level 0dBu
DIRECT OUTPUT TRS Jack socket Unbalanced
Output Impedance <150Ω
Minimum load >2kΩ
Nominal level 0dBu
REC OUTPUT RCA pin type Electronically Unbalanced
Output Impedance <150Ω
Minimum load >2kΩ
Nominal level -10dBv
PHONES OUTPUT TRS Jack socket Unbalanced
Minimum load >35Ω
Maximum power 100mW / 35Ω
LAMP XLR 4 type female(pin3=V+, pin4=V-)
Output Voltage 1.5V to 12V (between pin 3 and 4)
Operation Temperature -10°C~+35°C
Humidity 0 to 90% @35°C
Power Source DC ±18V/+48V
Power Consumption 300W(40ch, no signal)
Weight 62.7kg/138.22lb 75.3kg/166.00lb 88.5kg/195.10lb
Shipping Weight 99kg/218.25lb 116kg/255.73lb 134kg/295.41lb
Dimensions 1300(W)x220(H)x730(D)mm/ 1550(W)x220(H)x730(D)mm/ 1800(W)x220(H)x730(D)mm/
51.1(W)x8.7(H)x28.7(D)in 61.0(W)x8.7(H)x28.7(D)in 70.9(W)x8.7(H)x28.7(D)in
Frequency Response +0dB/-1dB(20Hz to 20kHz MIC to Mix O/P at +60dB input gain)
Noise Level Residual noise <-90dB(Mix O/P with no signal assignment, 20Hz to 22kHz)
Ein <-127dBu(MIC to Mix +60dB input gain with 150 ohms termination,20Hz to 22kHz)
C.M.R.R. > 80dB(@1kHz +40dB input gain)
> 60dB(@20kHz +40dB input gain)
Distortion <0.05%(20Hz to 20kHz, MIC to MIX O/P +16dB input gain at +20dBu output)
Cross Talk Fader Attenuation <-90dB @1kHz
Mute Attenuation <-90dB @1kHz
* Specifications and design subject to change without notice.
