MIXING CONSOLE
15
IMX-824/832/840
Mix Master/MTX Master
Mix Master/MTX Master
1. FRONT PANEL
1. MATRIX SENDS
MIX bus signals can be routed to the console’s 4
Matrix outputs in much the same way as a channel
feeds an auxiliary output. The send source can be
made pre-fader by pressing the PRE switch. In
pre-fader mode, matrix sends are unaffected by the
MIX output’s MUTE.
2. MUTE
Mutes the After-fader signal of the channel path.
Pre-fader signal, which provided to Matrix-PRE
path is NOT affected by this switch.
3. MASTER FADER
A 100mm stroke fader adjusts the channel signal
level continuously from to +10dB.
1
2
3
