8 TruVision 11/31 Series IP Camera Configuration Manual
Figure 1: Web browser interface
Table 1: Overview of the web browser interface
Name Description
1. Live view Click to view live video.
2. Playback Click to play back video.
3. Log Click to search for event logs. There are three main types: Alarm,
Exception and Operation.
4. Configuration Click to display the configuration window for setting up the
camera.
5. Viewer View live video. Time, date and camera name are displayed here.
6. Current user Displays current user logged on.
7. Logout Click to log out from the system. This can be done at any time.
8. Aspect ratio Select the aspect
9. Streaming Switch between main stream and substream.
10. Start/stop live view Click to start/stop live view.
11. Audio Adjust volume.
12. Bidirectional audio Turn on/off microphone.
13. Capture Click to take a snapshot of the video. The snapshot will be saved
to the default folder in JPEG format.
14. Start/stop recording Click to record live video.
15. Digital Zoom Click to enable digital zoom.
16. PTZ control Control pan, tilt, zoom actions, and set up presets and tour.
