P/N 146278999-2 (ML) • REV G • ISS 08MAR19 5 of 26
• Put the appropriate mirror stickers if necessary. See
Figure 8, item 1 for details.
Caution: Removing stickers can damage the mirror
surface.
• When near objects directly under the detector, fit the mask
to the inside of the window (default). This disables the part
of the curtains looking down at the object, whose
closeness might destabilize the detector. See Figure 8,
item 2.
LED indication
Continuously on Normal blinking (1 Hz)
Fast blinking (4 Hz)
Do a successful
walk test
* Depends on the setting of the DIP switch SW4.
Specifications
9 high-density mirror curtains
9 to 15 V (12 V nominal)
Normal current consumption
Current consumption in alarm
Maximum current consumption
1.8 to 3.0 m
(5.9 to 9.8 ft.)
2.0 to 3.0 m
(6.6 to 9.8 ft.)
30 cm/s to 3 m/s
(1 ft./s to 10 ft./s)
20 cm/s to 3 m/s
(8 in./s to 10 ft./s)
Alarm (NC) / Tamper relay
characteristic
−10 to +55°C (14 to 130°F)
108 × 60 × 46 mm
(4.25 × 2.36 × 1.81 in.)
