Intermec EasyCoder PD41 Spare Parts

Chapter 2 — Spare Parts
EasyCoder PD41 and PD42 Printer Spare Parts Catalog 9
Panels, Right
1
2
3
Callout Part Number Description Remarks
1 1-207070-900 Right-hand door Complete unit including hinges.
2 1-207046-900 Top right panel Display console board to main board.
3 1-207047-900 Bottom right front lid Includes thumbscrew.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
