Chapter 2 — Spare Parts
26 EasyCoder PD41 and PD42 Printer Spare Parts Catalog
Rewinder
Screw
(6 places)
Screw
Screw
Screw
Screw
(4 places)
3
2
1
Callout Part Number Description Remarks
1 1-207084-800 Rewinder module, internal Included is the liner retention guide. Rewinder
drive belt is not included.
2 074060-001 Liner retention clip
3 703-027800-021 Rewind drive belt, 140MXL025
