Chapter 1 — Getting Started
IF2 Network Reader User’s Manual 9
4 To set the IP address, press 1 and enter the static IP address in the
entry field.
5 Press Enter. The static IP address is set. If you do not need to set
the subnet mask or IP router values, you can now continue to
configure the IF2 through the web browser interface. For help, see
“Using the Web Browser Interface” on page 10.
If you need to change the values for subnet mask or the IP router,
continue with the next step.
6 To set the subnet mask, press 2 and enter the subnet mask value in
the entry field. Press Enter to save the changes.
To set the IP router address, press 3 and enter the IP router address
in the entry field. Press Enter to save the changes.
7 (Optional) To change the Ethernet link speed, press L and choose
a link speed from the list of options:
8 Press Q to close the Initial Configuration screen.
9 Disconnect the null-modem cable from the IF2.
The IF2 is now ready to be connected to your network. See
“Connecting the IF2 to Your Network” on page 15.
Ethernet Link Speed Options
To choose this speed: Press:
Auto detect (default) A
100 Mbps - full duplex 1
100 Mbps - half-duplex 2
10 Mbps - full duplex 3
10 Mbps - half duplex 4
Keep the current selection and close this dialog box Q
