Maintenance
The Advantage Dual Frequency Sonar has been designed to provide reliable, trouble-free performance for years.
Follow the maintenance tips below to ensure that your Advantage remains problem free.
1) Keep your Advantage clean and dry. Occasionally wipe unit off with a damp cloth, but be careful not to scratch
the lens covering the LCD screen. For stubborn dirt, use a mild soap and a damp cloth. NEVER USE SOLVENTS
SUCH AS PAINT THINNER, ACETONE, OR GASOLINE TO CLEAN YOUR Advantage.
2) Occasionally clean the face of the depth transducer (sensing surface) and carefully remove any marine growth.
Use a mild detergent, or 220 grit sandpaper, or crocus cloth to remove stubborn growth.
3) If the in-line fuse is blown, replace it with a 2 amp fuse. NEVER REPLACE WITH A HIGHER AMP RATING!
If the fuse continues to blow, check the polarity of your 12 VDC power source. If the polarity is correct, check with
the Technical Service Department at (831)477-4944.
4) In order to protect your transducer from water damage, paint it with one of the following brands: Interlux-
UltraCoat, Fiberglass Bottom Coat, Super Bottom Coat; Pettit-UniPoxy; Rule-Super KL, Gloss Dura Poxy. DO NOT
use a solvent based paint.
5) DO NOT allow any solvents, i.e. gasoline, acetone, to come in contact with the transducer or head unit as
these may dissolve the material.
Troubleshooting Guide
If you are experiencing trouble with your Advantage, please refer to the following checklist:
PROBLEM SOLUTION
Unit will not turn on. Check fuse, battery voltage and power connections.
Also, check for continuity through the in-line fuse holder.
Unit beeps but no picture appears Check your connections to the battery. Check for
on the screen. corrosion on the battery terminals or on the wiring
connections on a fuse block or buss bar.
Unit blows fuses. Wiring is reversed or there is excessive current from the
battery. The red wire should be “+” (positive) and have
continuity with pin #1 on the female side of the power
supply lead.
Loses picture at speed. Adjust the transducer angle or placement. Make sure that
the transducer is installed in the area which has the least
amount of water turbulence.
