PARAMETER
DESCRIPTION
VALUES
Dont Send Periodically: There will not be any
periodical sending to the bus.
Send While Button Pressing: The current input
value will be periodically sent to the bus while
the contact of the input is closed.
Send While Button Not Pressing: The current
input value will be periodically sent to the bus
while the contact of the input is opened.
Send While Button Not
Pressing
Send Always
Periodical Sending Interval
(sec)
1
This parameter determines the sending period
of the current input value.
60 (1…65535)
Locking
This parameter determines if the input can be
locked via an additional locking object or not.
Disabled: This option is disabled.
Lock On Value 0: When the locking
communication object takes the value 0, status
changes at the input are not transmitted.
Lock On Value 1: When the locking
communication object takes the value 1, status
changes at the input are not transmitted.
Disabled
Lock On Value 0
Lock On Value 1
1
This parameter is only visible when the parameter “Periodical sending” is set to “Send Always”, “Send While
Button Pressing” or “Send While Button Not Pressing”.
3.1.3. Objects
The following objects can be used through the switching function:
OBJ NAME
FUNCTION
TYPE
FLAG
InputX
ON / OFF
1 bıt
CRT
Switching telegrams are sent via the group address linked with this object.
InputX
Locking
1 bit
CRWU
This object is only visible when the locking function is enabled. Via the group address linked, it is possible
to lock the current input through the value configured previously.
