3. FUNCTIONS
3.1. SWITCHING
3.1.1. Description
This function is used to send switching values (ON
or OFF). Each time when the push button is pressed
and / or released a telegram is sent. The sent value
with every action will depend on the parameters
configurated.
3.1.2. Parameters
PARAMETER
DESCRIPTION
VALUES
On Press / On Release
This parameter determines the behaviour of the
switching button.
ON / - : when the contact is closed the value “on“
is sent.
OFF / - : when the contact is closed the value
“off“ is sent.
ON / OFF: when the contact is closed the value
“on“ is sent and when the contact is opened the
value “off” is sent.
OFF / ON: when the contact is closed the value
“off“ is sent and when the contact is opened the
value “on” is sent.
- / ON: when the contact is opened the value “on“
is sent.
- / OFF: when the contact is opened the value
“off“ is sent.
ON / -
OFF / -
ON / OFF
OFF / ON
- / ON
- / OFF
Sending Delay (sec)
This parameter set a delay between the action
and the sending of telegram to the bus. Value 0
means the immediate emission of the telegram.
0 (0…255)
Emission at Initialization
“Used” option allows sending the current values
of the inputs to the bus when the module is
energized. Otherwise, any telegram will be sent
after first powered on.
Not Used
Used
Periodical Sending
Send Always: The current input value will be
periodically sent to the bus.
Don't Send Periodically
Send While Button
Pressing
