Interra ITR102 - Objects

KNX Universal Interface
Product Manual
©2019 INTERRA 18 PM190207005BEN
3.4.3. Objects
The following objects can be used through the Shutter/Blinds function:
OBJ NAME
FUNCTION
TYPE
FLAG
InputX
SlatAngle/Stop
1 bit
CRT
The commands “SlatAngle” or “Stop” are sent via the group address linked with this object.
InputX
Up/Down
1 bit
CRT
The commands “Up” or “Down” are sent via the group address linked with this object.
InputX
Status
1 bit
CRWU
These objects are only visible with “Shutter/Blinds with 1 Button” function. Via the group address linked they
indicate the current status of a related output.
InputX
Locking
1 bit
CRWU
This object is only visible when the locking function is enabled. Via the group address linked, it is possible to
lock the current input through the value configured previously.
