PARAMETER
DESCRIPTION
VALUES
Selection
This parameter is used to configure whether the
Shutter/Blinds function works with 1 button or 2.
Shutter/Blinds with 1 Button: when the contact of the
input is closed briefly the values “down”, “stop”, “up”
and “stop” are sent sequentially.
Shutter/Blinds with 2 Buttons: when the contact of the
input is closed briefly the value “stop” is sent via
“SlatAngle/Stop” object. Otherwise if the the push-
button is pressed longer, the value “UP”
(corresponding to UP direction parameter) or “down”
(corresponding to DOWN direction parameter) is
sent via “Up/Down” object.
Shutter/Blinds with
1 Button
Shutter/Blinds with
2 Buttons
Direction
1
This parameter is used to configure if the inputX will
work as up or down.
Up
Down
Long Press Duration
1
This parameter determines the minimum period for
detecting a long push button action.
0.4 sec
0.5 sec
0.6 sec
0.7 sec
0.8 sec
0.9 sec
1.0 sec
Locking
This parameter determines if the input can be locked
via an additional locking object or not.
Disabled: This option is disabled.
Lock On Value 0: When the locking communication
object takes the value 0, status changes at the input
are not transmitted.
Lock On Value 1: When the locking communication
object takes the value 1, status changes at the input
are not transmitted.
Disabled
Lock On Value 0
Lock On Value 1
1
This parameter is only visible when the parameter “Selection” is set to “Shutter/Blinds with 2 Buttons”.
