Intertek MBU 400 - Power Spectral Density

INTERTEK TESTING SERVICES
Test Report Number: HK08060834-1 Page 22 of 72
FCC ID: T7HCT8015
Company: RTX Consumer Products Hong Kong Ltd. Date of Test: June 24-July 7, 2008
Model: MBU 400
4.6 Power Spectral Density, FCC Rule 15.319(d):
Power spectral density shall not exceed 3 mW (4.8dBm) in any 3 kHz bandwidth as
measured with a spectrum analyzer having a resolution bandwidth of 3 kHz.
Measurements are made in accordance with ANSI C63.17 sub-clause 6.1.5. Test setup is
shown in section 3.2 Figure 3.2.1.
Test Results:
I. Traffic Carrier
Channel Channel Frequency
(MHz)
Measured Power
Spectral Density
(dBm/3kHz)
Limit
(dBm/3 kHz)
Results
Lowest 1921.536 -5.2 4.8 Pass
Highest 1928.448 -5.7 4.8 Pass
II. Dummy Carrier
Channel Channel Frequency
(MHz)
Measured Power
Spectral Density
(dBm/3kHz)
Limit
(dBm/3 kHz)
Results
Lowest 1921.536 -10.5 4.8 Pass
Highest 1928.448 -11.9 4.8 Pass
Please refer to the attached plots for more details:
Plot 3A: Lowest Channel Power Spectral Density (Traffic Carrier)
Plot 3B: Highest Channel Power Spectral Density (Traffic Carrier)
Plot 3C: Lowest Channel Power Spectral Density (Dummy Carrier)
Plot 3D: Highest Channel Power Spectral Density (Dummy Carrier)
The plots of the power spectral density are saved as filename: psd.pdf
