Intertek MBU 400 - Monitoring Bandwidth

INTERTEK TESTING SERVICES
Test Report Number: HK08060834-1 Page 52 of 72
FCC ID: T7HCT8015
Company: RTX Consumer Products Hong Kong Ltd. Date of Test: June 24-July 7, 2008
Model: MBU 400
4.22 Monitoring Bandwidth, FCC Rule 15.323(c)(7).1:
The monitoring bandwidth must be equal to or greater than the emission bandwidth of the
intended transmission.
Measurements are made in accordance with ANSI C63.17 sub-clause 7.4. Test setup is
shown in section 3.3 Figure 3.3.1.
Attestation:
[ × ]
Monitoring is made through the radio receiver used by the EUT for
communication. Please refer to the Exhibit 2.2 Technical Description for more
details.
[ × ]
Compliance is demonstrated by Monitoring Bandwidth Tests as shown below.
Test Results:
I. Simple Compliance Test Results:
Interference from Carrier Reaction of EUT Results
-30% EBW NA NA
+ 30% EBW NA NA
II. Detailed Compliance Test Results:
CW Interference from Carrier Reaction of EUT Results
+ 6 dB NA NA
+ 12 dB NA NA
- 6 dB NA NA
- 12 dB NA NA
A – Could Transmit
B – Could not Transmit
NA – Not applicable
*Remarks: Detailed Compliance Test was used to show the compliance of the EUT.
