193
GS
SAVE THESE INSTRUCTIONS
(193GS) MODEL SF90220T SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 09/15/2017
English
Page 13
SAND FILTER PUMP HOSE CONNECTION SETUP (continued)
For INTEX pool with 1-1/4” (32mm) connections/hoses:
Make sure the air jet valve
(38)
is securely tighten onto the pool inlet air adaptor
(40)
and facing
up.
For NON-INTEX pool:
Connect the hose
(12)
to the pool inlet/outlet connection with a large hose clamp. Tighten
securely.
POOL
LARGE HOSE
CLAMP
12
3
41
28
(Adaptor B)
40 38
30
29
31
23
28
(Adaptor B)
23
To Next Page
