English
STATIONARY MOUNTING
Some countries, especially in the European community, require the product
to be secured to the ground or to a base in a permanent upright position.
Check with your local authorities to determine if there is a regulation in your
area regarding above-the-ground swimming pool filter pumps. If yes, then
the product can be mounted to a platform using the two holes located in the
base. See drawing below.
The product can be mounted on a cement base or onto a wooden platform
to prevent accidental tipping. Total assembly must exceed 18kg .
1. The mounting holes are 6.4 mm in diameter and spaced 125 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
125 mm
SAVE THESE INSTRUCTIONS
Page 18
