Intex SF90110T User Manual

193
PO
SAVE THESE INSTRUCTIONS
(193PO) MODEL SF90110T SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/21/2013
English
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO. DESCRIPTION QTY.
SPARE PART
NO.
1 PRESSUREGAUGE 1 11720
2 TANKCOVER&6-WAYVALVESET 1 11721
3 DRAINOUTLETCOVER 1 11131
4 CLAMPASSEMBLY 1 11722
5 TANKO-RING 1 11728
6 SANDFILTERPUMPMOTORINLETO-RING 1 10712
7 CENTERPIPE 1 11729
8 FILTERGRID 1 11730
9 DRAINVALVECAP 1 11456
10 DRAINVALVEO-RING 1 11385
11 L-SHAPEO-RING 4 11228
12* HOSEWITHNUTS 2 11009
13 SANDFILTERINTERCONNECETINGHOSE 1 11763
14 TRANSPARENTOUTLETADAPTOR 2 11723
15 TRANSPARENTOUTLETADAPTORO-RING 4 11724
16 CLAMPPIN 1 11726
17 CLAMP SCREW 1 11727
18 L-SHAPEO-RING 1 11412
19 TRANSPARENTLEAF TRAP 1 11733
20 PUMP MOTOR 1 11734
21* PLUNGERVALVE(HOSEO-RING&STEPWASHERINCLUDED) 2 10747
22*
HOSEO-RING
2 10262
23* STEP WASHER 2 10745
24* STRAINERNUT 2 10256
25* FLATSTRAINERRUBBERWASHER 2 10255
26* THREADEDSTRAINERCONNECTOR 2 11235
27* ADJUSTABLEPOOLINLETNOZZLE 1 11074
28* ADAPTOR B 2 10722
29* STRAINERCONNECTOR 2 11070
30* POOLINLETNOZZLE 1 11071
31* STRAINERGRID 1 11072
32 10"SANDFILTERPUMPTANK 1 11731
33 10"SANDFILTERPUMPTANKBASE 1 11732
34 TRANSPARENTOUTLETADAPTORSCREW 4 11725
35* VACUUMRELEASEVALVECAP(NOTSHOWN) 2 11576
36* VACUUM RELEASE VALVE 2 11437
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
Page 5

Intex SF90110T Specifications

General

Brand	Intex
Model	SF90110T
Category	Swimming Pool Pump
Language	English
