2.1.4 Footrest supports
- Standard footrest supports (photo 9) they swing away du-
ring transfers and can be removed during transport.
Operate lever (A) by pushing sideways and swivelling towards
outside or inside in case there is not enough space. To re-
turn to the initial position, align the footrest support it locks
automatically.
To remove the footrest support, simply pull up after
unlocking the assembly. Reverse the procedure to reassem-
ble, while still in the unlocked position.
- Legrest (photo 10) performs the same operation as for the
footrest support to swing away or remove the legrest, by
operating lever (A) which unlocks the locking system.
To adjust the angle, support the leg with one hand while
loosening the locking knob (B) with the other hand. Lift or
lower the legrest in the desired position and rmly tighten
the knob (B).
The calfpad swings away during transfers and is height
adjustable by sliding. After loosening the screw (C), adjust
to the desired height and rmly tighten the screw (C). In
addition, it is depth adjustable loosen the screw (D), bring to
new position and rmly tighten the screw (D).
9
10
C
D
A
B
A
