Invacare Action 3 - Tools for adjustments and regular maintenance; Dimensions

32
33
3.2. Tools for adjustments and regular maintenance
(not supplied)
Function Tool
Brake 5 mm Allen key
Footrest tube 5 mm Allen) key
Footplate 5 mm Allen key
Adjustable armrests 5 mm Allen key
Simple armrests [1] 4 mm Allen key
10 mm open-end wrench
Armpad T20 Torx key
Castor 13 mm open-end Wrench(X 2)
Rear wheel xed axle 19 mm open-end wrench(X 2)
Quick-release axle 19 mm open-end wrench
11 mm open-end wrench
After sale and disposal recommendations
• It is compulsary to use original Invacare
®
spare parts which
you can buy through any Invacare
®
dealer.
• For repair, please contact your local Invacare
®
dealer.
• Disposal : the metal parts can be disposed of for scrap
metal through recycling. Plastic parts are disposed of as plastic
scrap metal. Plastic parts are disposed of as plastic scrap. Dis-
posal must be carried out in accordance with the respective
national regulation. Please apply to your municipal authorities/
local government for details about local disposal companies.
Picture Description
Min/Max
value
Picture Description
Min/Max
value
Seat effective
width (mm)
Backrest
height
including
headrest
(mm)
Overall
lenght
(mm)
Lenght
without
footrest
(mm)
Backrest
angle
( 0° )
Bracket
angle
( 0° )
Distance
betwee
n
front wheel an
d
rear wheel
(mm)
Distance
betwee
n
footrest and
seat (mm)
Distance
betwee
n
armrest and
backrest
(mm)
Overall
width (mm)
Width of
folded
wheelchair
(mm)
To
tal
height
(mm)
Height from
ground to
back seat
(mm)
Height from
ground to
front seat
(mm)
Wheelchair
height when
backrest is
folded (mm)
Backrest
height
(mm)
380/505
570/695
285
815/1020
395/510
410/510
400/510
625/750
1045/
1290
1000
717/857
362/550
0/30
80
350/480
250/350
3.3. Dimensions
