29
- Dual handrim :
Two systems allow the user to drive the wheelchair with a
single arm using two handrims on the same wheel (right or
left available).
• Fixed (photo 30) : the wheel axles are xed, folding is the
same as for a regular wheelchair.
• Quick release (photo 31) : the removable and inter-
changeable rear wheels facilitate transport as well as the
replacement of the control side.
To fold the wheelchair, disengage the transmission shaft (A)
by sliding the two rings (B and B')). To facilitate this opera-
tion apply a front to rear motion to the outside handrim.
To roll the folded wheelchair, separate the two wheels (one
centimetre) by pushing the buttons of quick-release axles.
Make sure that the wheels are still engaged!
Several types of braking adapted to your specic needs
are available. Please consult with your dealer upon agree-
ment by your prescribing physician.
2.6.3 Safety options
- Support belt
• Velcro fastener (photo 32) : position the two Velcro strips
one over the other based upon the user’s build.
• Buckle safety fastener (photo 33) : to close the buckle,
engage part (A) into part (B), to open press (C).
Straps should be adjusted to suit user, insert into part (B) of
the buckle and adjust the loop (D) based on the remaining
length.
The belt xing should be conform to the scheme en-
closed with each belt delivery; the belt should be mounted
and ajusted by your regular dealer.
Make sure that the belts do not get caught in the spokes of
the rear wheel.
The support belt must not be used as safety belt in a car.
32 33
B
A
C
D
30
31
B
A
B'
