Invacare Colibri - Adjusting Seat Height; Adjusting Tiller Angle

Setup
1.Pulltheleverupwardstodisengagetheseat.
2.Holdtheseatrmlybythebackrestandfrontedgeand
removeitupwards.
Installingtheseat
1.Lowertheseatassemblyontotheseatpost.
2.Allowtheseattodropintothelockedposition.
3.Liftupontheseatassemblytoensuretheseatissecure.
4.6Adjustingtheseatheight
Theseatheightcanbeadjustedto390,410,or430mm.
Requirements:
•2xopen-endedspanners17mm
1.Removetheseat.
2.
RemovetheseatpostlockingboltAusingboth
open-endedspanners.
3.
Adjusttheseatheight.
4.Replacethesecuringboltandtighten.
4.7Adjustingthetillerangle
WARNING!
Riskofinjuryiftillerisnotlockedintoposition
–Ensurethatthetillerisproperlyadjusted
beforedrivingthescooter.
–Aftermakinganytillerangleadjustments
andbeforeuse,thetillerMUSTbesecurely
lockedintoposition.Otherwise,afallfromthe
scootercouldoccurcausingbodilyinjuryand/or
damagetothescooter .Gently,push/pull
againsttillertoensurethatthetillerissecurely
engagedintotheadjustmentplate.
Thetillerlocksintooneofthreepositions.Thetillercan
alsobefoldeddownfortransportationandstorage.
Adjustingthetillerangle
