7Transport
7.1Transport-Generalinformation
WARNING!
Riskofsevereorfatalinjuriesintheevent
ofatrafcaccidentifthismobilitydeviceis
usedasavehicleseat!Itdoesnotfulllthe
requirementsofISO7176-19:2001.
–Undernocircumstancesshouldthismobility
devicebeusedasavehicleseatortotransport
theuserinavehicle.
7.2Dismantlingthescooterfortransport
Pleaseproceedasfollowstodismantlethescooterfor
transport:
1.Removetheseat.Referto4.5Disengagingtheseatto
rotateitorremoveit,page22.
2.Removethebatterybox.Referto7.2.1
Removing/Installingthebatterybox,page36.
3.Removethedriveunit.Referto7.2.2Removingthe
driveunit,page37.
4.Foldthetillerdowntothelowestlockedposition.Refer
to4.7Adjustingthetillerangle,page23.
7.2.1Removing/Installingthebatterybox
CAUTION!
Riskofstrainsfromliftingheavyparts!
–Useproperliftingtechniques.
CAUTION!
Riskofinjuryfromunsecuredscooterparts
Removingthebatteryboxwillreleasethe
LITE-LOCK™mechanismallowingthefrontframe
assemblytoseparatefromtherearframe
assembly.
–Donotliftormovethescooterwithoutthe
batteryboxunlessyouwanttodisassemble
it.Referto7.2Dismantlingthescooterfor
transport,page36.
Removingthebatterybox
1.Removetheseat.Referto4.5Disengagingtheseatto
rotateitorremoveit,page22.
2.
Grabthehandleofthebatterybox,pullthebatterybox
latchAwithyourthumbandremovethebatterybox.
Installingthebatterybox
1.Removetheseat.Referto4.5Disengagingtheseatto
rotateitorremoveit,page22.
2.Holdingthebatteryboxhandle,carefullylowerthe
batteryboxontothebatterytrayinthescooter.
3.Pressdownthebatteryboxtoengagetheconnectoron
thebatteryboxwiththeconnectoronthescooterbase.
