7.5 Installing Or Adjusting Lateral Supports (where fitted)
INSTALLING:
1. Remove the required existing pan head screws from each
backrest flange.
2. Line up the support rail (A) with the holes in the backrest.
3. With the longer screws provided attach the support rail to
the backrest flanges and into the screw inserts – DO NOT
screw into the backboard.
4. Tighten securely, but do not over tighten.
ADJUSTING:
1. Slide the lateral support into the support rail from the
bottom. Adjust to suit, and then firmly tighten the hand
wheel (B).
B
A
