REMOVAL:
1. Remove the legrests, or swing them out of
the way.
2. Loosen the handwheel (A) and then slide the
handwheel towards the centre of the chair.
3. Pull the kerb climber assembly away from
the retaining socket on the right hand side.
INSTALLING:
1. Locate the kerb climber into the right hand
retaining socket.
2. Slide the handwheel (A) outwards until the
assembly is also fitted into the left hand
retaining socket.
3. Tighten the handwheel (A) firmly.
A
