41
7.8 Installing / Removing Or Adjusting Headrest (where
fitted)
CAUTION:
After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened
securely - otherwise injury or damage may result.
INSTALLING:
1. Ensure set screws are not protruding into headrest
support tube.
2. Insert headrest assembly into headrest support tube.
3. Tighten the handwheel (A) to secure.
REMOVAL:
1. Loosen the handwheel (A).
2. Remove headrest assembly from headrest support tube.
ADJUSTING:
1. Loosen the headrest handwheels (A & B).
2. Adjust to desired position.
3. Re-tighten handwheels.
NOTE:
Ensure all headrest assembly adjustment screws, nuts and handwheels are tightened before using the
wheelchair.
B
A
