Invacare Insignia - Replacing Rear Wheel Handrim; Replacing;Repairing Rear Wheel Tire

SECTION 7—REAR WHEELS
Insignia
™
32 Part No. 1163197
5. Reinstallrearwheelontothewheelchair.RefertoRemoving/InstallingRearWheelsonpage 30.
FIGURE 7.2 Adjusting Quick-Release Axle
Replacing Rear Wheel Handrim
NOTE:Forthisprocedure,refertoFIGURE 7.3.
1. Removetherearwheelfromthewheelchair.Referto
Removing/Install ingRearWheels
onpage 30.
2. Removethemountingscrewsthatsecurethehandrim
totherearwheel.
3. Removetheexistinghandrim.
4. Installthenewhandrimbyreversingthepreceding
steps.
FIGURE 7.3 Replacing Rear Wheel Handrim
 WARNING
Make sure detent pin and detent balls of the quick-release axles are fully released before
operating the wheelchair.
5. Reinstallrearwheeltothewheelchair.RefertoRemoving/InstallingRearWheelsonpage 30.
6. Ifthedetentballsofthequick‐releaseaxles(ifapplicable)arenotprotrudingpasttheinsideoftheaxlebushingorthere
istoomuchmovementoftherearwheelassemblyinabackandforthposition,refertoAdjustingQuick‐ReleaseAxle

onpage 31.
7. RepeatSTEPS1‐6fortheoppositerearwheelifnecessary.
Replacing/Repairing Rear Wheel Tire
 WARNING
Replacement of rear wheel tire or tube MUST be performed by a qualified technician.
Quick-Release Axle
Detent Balls
Mounting Screw
Rear Wheel
Handrim
