SECTION 11—OPTIONS
Insignia
™
48 Part No. 1163197
Installing Crutch and Cane Carrier
WARNING
Check base weekly to ensure proper placement.
When loading the crutch/cane carrier, ensure items are securely placed into the base. Also ensure
that there is no interference with folding the wheelchair, the rear wheels, or the swing-back arms.
Strap MUST be securely fastened while carrying items.
NEVER insert or remove items while wheelchair is moving.
NOTE:Forthisprocedure,refertoFIGURE 1 1 .8.
1. Slidetheclampwiththebaseattachedovertheendofthesteptubeofthewheelcha ir.Ensurethebaseistowardstheinside
ofthewheelchai r.
2. Position thebaseparalleltothesteptube.
CAUTION
Base should be parallel to step tube to avoid
bending spokes when folding the wheelchair.
3. Securelytightenthelocknutthatsecuresthebasetothe
steptubeofthewheelchair.
4. Removetheupperbackupholsteryscrewandwasher.
5. Alignthe strapwiththebackupholsteryscrewmounting
hole.
6. Reinstallthebackupholsteryscrewandwasherand
securethestraptothewheel chair.
7. Thebasecleanseasilywithany
chromeorglasscleaner.
Thestrapcanbecleanedwithmildsoapandwater .
FIGURE 11.8 Installing Crutch and Cane Carrier
Installing/Removing the Seat Positioning Strap
Installing
NOTE:Forthisprocedure,refertoFI GURE 11.9onpage 49.
NOTE:Rightandleftisdeterminedbysittinginthewheelchair.
1. Removethemountingscrewandlocknutthatsecurethebackanglebrackettothewheelchair .
2. Securethebucklestraptothebackanglebracketontherightsideofthewheelchairwith
mountingscrewandlocknut.
Tightensecurely.
3. Securethetonguestraptothebackanglebracketontheleftsideofthewheelchairwithmountingscrewandlocknut.Tighten
securely.
Removing
1. Removethemountingscrewandlocknutthatsecuresthebucklestraptothebackanglebracket.
2. Removethebucklestr ap.
3. Securethebackanglebrackettothewheelchairframewiththemoun tingscrewandlocknut.Tightensecurely.
4. Removethemountingscrewandlocknutthatsecuresthetonguestraptothebackangle
bracket.
5. Removethetonguestrap.
6. Securethebackanglebrackettothe wheelchairframewiththemountingscrewandlocknut.Tightensecurely.
