SECTION 11—OPTIONS
Part No. 1163197 49 Insignia
™
FIGURE 11.9 Installing/Removing the Seat Positioning Strap
DETAIL “A”
Buckle
Buckle Strap
Tongue
Tongue Strap
DETAIL “B”
Mounting Screw
and Locknut
Buckle Strap
NOTE:Rightsideofwheelchair
shown.Rearwheelremovedforclarity.
Right Side of
Wheelchair
Left Side of
Wheelchair
Buckle and Tongue
Connected
DETAIL “C”
