Using the O2 Holder
 WARNING
Only use O2 cylinders that are at least 10.7 inches in height and 4
3
/
8
inches in diameter. Smaller O2
cylinders will not secure in place properly which may result in injury and/or damage to the cylinder.
NOTE:Forthisprocedure,refertoFI GURE 11.3.
1. PlacetheO2cylinderintheO2holderasshown(Det ail“A ” ) .
2. SecuretheO2cylinderinplacebyrotating thelockingknobclockwise(Detail“B”).Handtightenonly.
FIGURE 11.3 Using the O2 Holder
Cleaning the O2 Holder
 WARNING
The user and O2 cylinder MUST be removed from the wheelchair when cleaning the O2 holder.
Otherwise, injury or damage may occur if cleaning agents come in contact with the O2
regulator.
1. RemovetheuserandtheO
2
cylinderfromthewheelchair.
2. TheO2holdercleanseasilywithanyhouseholdglasstypecleaner.
NOTE:Afterthecleaningsolutionhasdried,itissafefortheusertore‐occupythewheelchair.
NOTE:O2holdershownisnotinstalledonthewheelchairforclarity.
O2 Cylinder
Locking Knob
DETAIL “A”
O2 Holder
DETAIL “B”
O2
Holder
O2 Cylinder
