SECTION 10—ANTI-TIPPERS
Insignia
™
40 Part No. 1163197
Adjusting Anti-Tippers
NOTE:Forthisprocedure,refertoFIGURE 10.3.
1. Pressthereleasebuttonsonthewheeledportionofthe
anti‐tipperandslideitupordowntoachievethe1‐1/2
to2‐inchclearance(Detail“A ” ) .
2. Checktomakesurethatthereleasebuttonsarefully
engagedinadjustmentholes.
FIGURE 10.3 Adjusting Anti-Tippers
NOTE:RefertoDetail“B”inFIGURE 10.3andtothefollowingcharttoensurethecorrectanti‐tipperisinstalledinthewheelchair.
Seat‐to‐Floorheightsareapproximatedependingonfrontcastersizeandtype.Anti‐Tipperlengthmeasurementistakenwiththe
extensiontubeinthelongest positionavailable.The
anti‐tipperheightmeasurementMUSTbetakenwiththeanti‐tipperonaflatsurface.
1½ inches
Release Buttons
2 inches
Anti-Tipper
Length
Anti-Tipper
Height
DETAIL “B”
DETAIL “A”
INSIGNIA
CASTER
SIZE
SEAT-TO-FLOOR HEIGHT ANTI-TIPPER
LENGTH/HEIGHT
6-inch and
8 inch
16½, 17½, 18½, 19½ inches 13.5/3.8-inches
