SECTION 4—TYPICAL PRODUCT PARAMETERS

Part No 1118353 13 Platinum

™

Series

SECTION 4—TYPICAL PRODUCT

PARAMETERS

*NOTE:Statedconcentrationlevelsachievedafterinitialwarm‐up

period(approximately30minutes).

Electrical Requirements: 120 VAC ± 10% (132 VAC/108 VAC), 60

Rated Current Input: Platinum 5 and XL: 4.3 A

Platinum 10: 4.7 A

Sound Level: Platinum 5 and XL: 50 dB Average

Platinum 10: 58 dB Average

Altitude: Platinum 5 and XL - Up to 6,000 ft (1828

meters) above sea level without degradation

of concentration levels. From 6,000 ft (1828

meters) to 13,129 ft (4000 meters) below

90% efficiency

Platinum 10 - Up to 4,000 ft (1230 meters)

above sea level without degradation of con-

centration levels. From 4,000 ft (1230

meters) to 13,129 ft (4000 meters) below

90% efficiency

*Oxygen Output

Concentration Levels:

All 5LXO2/5LX models 87% to 95.6% for

flows ranging 0.5 to 5 L/min and all

10LXO2/10LX models 87% to 95.6% for

flows ranging 2 L to 10 L/min

Maximum Outlet Pressure: Platinum 5 and XL: 5 psi ± 0.5 psi (34.5 kPa

± 3.45 kPa)

Platinum 10: 9 psi ± 0.5 psi (62.0 kPa ± 3.45

kPa)
